Shoe mold Silicone Rubber

Product introduction

SHOE MOLDING SILICONE RUBBER DESCRIPTION

Duplicating for pouring or brushing way, for shoe mold , artificial stones,

gypsum crafts, concrete products, GRC, GRG, GFRC, fireplaces,

fountains, ornaments, resin crafts, art sculptures, decorations, PU,

furniture molding, candle crafts, plastic crafts, Buddhist statue crafts


LHSIL RTV silicone rubber is mainly used for

shoe molds, sand casting,

sole sampling, plaster models,

simple products,

products with non-complex patterns,

product models with stable size and non-deformation.

  DATASHEET OF SHOE MOLD SILICONE RUBBER

Product

Catalyzed

Viscosity:cps

Base

Color

Specific

Gravity

Mixed

Ratio

Shore A Hard

Tear

KN/m

Tensile

kgf/c



Elongation

%

LHSIL RTV

22,000

         white

1.15

100:2

20-22

≥32

≥3.6

≥580

LHSIL RTV

25,000

white

1.15

100:2

25-26

≥35

≥4.7

≥550

LHSIL RTV

30,000

white

1.21

100:2

30-32

≥35

≥5.0

≥500



 Note: Above technical datasheet of two parts silicone rubber it's adjustable according to customer's requirements.

SHOE MOLDING SILICONE RUBBER MOLDING INSTRUCTION:

 mould grade silicone rubber is a kind of white flowing liquid. If the customer wants to make large products and large size molds, the mold should be made of rtv mould rubber with high hardness. On the contrary, if the mold with fine and precision patterns, it should be made of rtv mould rubber with low hardness. The amount of the curing agent depends on the actual requirements of the customer.

USING INSTRUCTION OF SHOE MOLD SILICONE:

Component A is white flowing liquid and component B is the curing agent.

For example, take silicone rubber of 100g and add 2% curing agent for mixing evenly.

After the silicone rubber and the curing agent are completely mixed,

put the silicon into a vacuum machine for deairing to remove the bubbles.

After deaired, pouring the liquid silicone rubber into the product to be duplicated or into the mold frame.



USING NOTE OF SHOE MOLD SILICONE:

For products size (within 20cm),

with details designs, soft silicone is suitable, such as 10-20 shore A.
- For products size (20cm-80cm),
with intricate designs, 20-25 shore A is suitable.
with simple designs, 25-30 shore A is suitable.

- For products size (80cm-150cm),
with intricate designs, 25 shore A is suitable.
with simple designs, 30-35 shore A is suitable.

- For products size (more than 150cm),
with details designs, 25-28 shore a A is suitable.
with simple designs, 35-40 shore A is suitable.

STORAGE AND PRECAUTIONS OF SHOE MOLD SILICONE:

The product, which is an environmentally-friendly liquid silicone product,

 is not easy to burn and can be stored and transported as non-hazardous goods.

Inspection is required when exceeding the time limited.



PACKAGE OF SHOE MOLD SILICONE:
25KG/drum vacuum packing for part A +1kg/ bottle catalyst for part B
200KG/drum packing for part A +1kg/ bottle catalyst for part B



SHELF LIFE OF SHOE MOLD SILICONE:
1.Twelve(12) months when stored under dry and cool place by original package under 25℃


Contact Lianhuan:

SHENZHEN LIANHUAN SILICONE CO.,LTD

Email: nancy@lhsilicone.com

Skype: nancyxie2007

WeChat0086 13699849627

Ms Nancy Cell/WhatsApp: +86 13699849627



Product use

       Shoe Mold silicone rubber usage:

        Shoe soles mold, pouring mold, sand casting

  • Product Name: Shoe mold silicone

  • Product No.: LHSIL RTV

  • Brand: Lianhuan silicone

  •
